Product Introduction
4 Output 12VDC - 5A - UL
|
Model |
AP1204-5P （Ⅱ） |
|
Input Voltage |
AC 100~240V, 50-60Hz |
|
Output Voltage |
DC11V-15V |
|
Total Output Current |
5A |
|
Total Output Channel |
4CH |
|
Fuse type |
PTC Resettable |
|
Fuse Rating |
2A |
|
Ripple & Noise |
<=120mv |
|
Efficiency |
>=88% |
|
Storage Temperature |
-40—85℃ |
|
Operating Temperature |
-20—60℃ |
|
Certificate |
UL,VI,CE,FCC |
|
Product Net Weight |
419g |
|
Product Dimension |
138.6*54.8*37mm |
|
Certificate |
UL,CEC,CE,FCC |
|
Warranty |
2 Year |
